CASE CONSTRUCTION CX37C - 2-way selection proportional switch (Optional); Breaker trigger switch (Optional)

9-ACCESSORIES
2-wayselectionproportionalswitch(Op-
tional)
Clamshellorshearcanbeoperatedbymeansofthepro-
portionalswitchontheright-handcontrollever.Thisfunc-
tionappliestodoubleactionhydraulicattachmentcircuit.
Thebasicoperationofthe2-wayselectionproportional
switcharethefollowing:
•
Operatetheproportionalswitchtothelefttoopenthe
clamshellorshear.
•
Operatetheproportionalswitchtotherighttoclosethe
clamshellorshear.
ConsultyourCASECONSTRUCTIONdealertoselectthe
optionalaccessorycompatiblewithyourmachineandto
correctlyadjusttheowrequiredforitsuse.
(B)Hornswitch.
SMIL16MEX1265BA4
Breakertriggerswitch(Optional)
Thebreakercanbeoperatedbymeansofthetrigger
switchlocatedontheright-handcontrollever.
NOTE:thebreakeroperatesonlywhenthebreakerse-
lectionswitchontheswitchpanelisselected.
Thisfunctionappliestosingleactionhydraulicattachment
circuit.
Whenbreakeroperatingisnished,stopengineandpush
thetriggerswitchtoreleasepressureinthebreakercir-
cuit.
ConsultyourCASECONSTRUCTIONdealertoselectthe
optionalaccessorycompatiblewithyourmachineandto
correctlyadjusttheowrequiredforitsuse.
SMIL16MEX1502BA5
9-4
