4-OPERATINGINSTRUCTIONS
10.Operatethebucketcontroltoretractthecylinderrod
andallowthesafetydevicetoengage.
SMIL13CEX2703AB10
Disassembly
1.Operatethearmandbucketcontrolssothatthedipper
ispracticallyvertical,slopingslightlytowardsthecab,
toreleasethesafetydevice.Extendthebucketcylin-
derrodcompletelyandmaintainthehydraulicpres-
suresothatthelatchinghookretracts.
SMIL13CEX2704AB11
2.Placetheswitch(1)inunlockingposition.Theaudible
alarmdevicewillsound.
SMIL13CEX2696AB12
3.Operatethebucketcontroltolaythebucketsafelyon
at,levelground.
SMIL13CEX2705AB13
4-22
