CASE CONSTRUCTION CX75C SR - Page 237

8-SPECIFICATIONS
Bladetype
SMIL13CEX2898FB2
Arm
1.69m(66.54in)2.19m(86.22in)
(A)2600mm(102.36in)(*)
(B)2760mm(108.66in)2760mm(108.66in)
(C)5755mm(226.57in)(*)
(D)3410mm(134.25in)3410mm(134.25in)
(E)2270mm(89.37in)2270mm(89.37in)
(F)750mm(29.53in)750mm(29.53in)
(G)(*)1425mm(56.10in)(*)
(H)2845mm(112.01in)2845mm(112.01in)
(I)2210mm(87.01in)2210mm(87.01in)
(J)1870mm(73.62in)1870mm(73.62in)
(K)(standardtrackpads)450mm(17.72in)450mm(17.72in)
(L)2320mm(91.34in)2320mm(91.34in)
(M)360mm(14.17in)360mm(14.17in)
(N)1855mm(73.03in)1855mm(73.03in)
NOTE:(*)whentransportingthemachineincaseof2.19m(86.22in)arm,positionthebladetotheoppositesideof
theattachment.Inthisposition,thedimensions(A),(C)and(G)arethefollowing:
(A):2860mm(112.60in)
(C):6340mm(249.61in)
(G):1990mm(78.35in)
8-5
