k Using Recursion Table & Graph Functions in a Program
Incorporating Recursion Table & Graph functions in a program lets you generate numeric
tables and perform graphing operations. The following shows various types of syntax you
need to use when programming with Recursion Table & Graph functions.
• Recursion formula input
an+1 Type_ .... Specifies recursion type.
”3an + 2” → an+1_
”4bn + 6” → bn+1_
• Table range setting
1 → R Start_
5 → REnd_
1 → a0_
2 → b0_
1 → an Start_
3 → bn Start_
• Numeric table generation
DispR-Tbl_
• Graph draw operation
Connect type: DrawR-Con_, DrawRΣ-Con_
Plot type: DrawR-Plt_, DrawRΣ-Plt_
• Statistical convergence/divergence graph (WEB graph)
DrawWeb an+1, 10_
8-6-7
Using Calculator Functions in Programs

Casio fx-9860G AU Specifications

General

Display Type	LCD
Display Size	128 x 64 pixels
Connectivity	USB
Model	fx-9860G AU
Category	Graphing Calculator
Power Source	4 AAA batteries
Programming	Yes (Casio BASIC)
Dimensions	184 x 91 x 21 mm
