20070201
1-5 Variable Data (VARS) Menu
To recall variable data, press J to display the variable data menu.
{V-WIN}/{FACT}/{STAT}/{GRPH}/{DYNA}/
{TABL}/{RECR}/{EQUA*
1
}/{TVM*
1
}
See “8-7 PRGM Mode Command List” for details on the variable data (VARS) menu.
u V-WIN — Recalling V-Window values
• {X}/{Y}/{T, Ƨ }
... { x -axis menu}/{ y -axis menu}/{T, Ƨ menu}
•
{R-X}/{R-Y}/{R-T, Ƨ }
... { x -axis menu}/{ y -axis menu}/{T, Ƨ menu} for right side of Dual Graph
• {min}/{max}/{scal}/{dot}/{ptch}
... {minimum value}/{maximum value}/{scale}/{dot value*
2
}/{pitch}
u FACT — Recalling zoom factors
• {Xfact}/{Yfact}
... { x -axis factor}/{ y -axis factor}
1-5-1
Variable Data (VARS) Menu
*
1
The EQUA and TVM items appear only when
you access the variable data menu from the
RUN
•
MAT, PRGM or e
•
ACT mode.
# The variable data menu does not appear if
you press J while binary, octal, decimal,
or hexadecimal is set as the default number
system.
*
2
The dot value indicates the display range (Xmax
value – Xmin value) divided by the screen dot
pitch (126).
The dot value is normally calculated
automatically from the minimum and maximum
values. Changing the dot value causes the
maximum to be calculated automatically.
