Casio TR-M11 User Manual

34
Quick Start Basics
Flick from the edge of the screen in the direction of the arrows.
Shooting Settings
Selfie timer*
1
(page 37)
Make-up*
2
(page 36)
LED light
(page 38)
Recording Mode*
3
(page 35)
*1 “Delete” operations will be activated
when in the playback mode.
*2 There are cases in which this item
will not be displayed depending on
the shooting mode selected.
*3 “Send Image” operations will be
activated when in the playback
mode.
The angle at which the setup screen
is displayed will change to 90-
degrees when the screen is set to a
90-degree horizontal view.

Casio TR-M11 Specifications

General

Megapixel	10.5 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	No
Total megapixels	12.76 MP
Image sensor size	1/2.3 \
Image formats supported	EXIF, JPEG
Supported aspect ratios	1:1, 4:3
Maximum image resolution	- pixels
Still image resolution(s)	4:3 (12M 4000 x 3000) / 1:1 (8M 2976 x 2976)
Bluetooth	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Scene modes	-
White balance	Auto
Self-timer delay	2, 3, 5, 10 s
Digital zoom	4 x
Optical zoom	- x
Fixed focal length	3.8 mm
Maximum aperture number	2.8
Lens structure (elements/groups)	5/5
Auto focusing (AF) modes	Spot Auto Focus
Normal focusing range (tele)	- m
Product color	Green
Light metering	Evaluative (Multi-pattern)
Light exposure control	Program AE
Power source type	Battery
Camera shutter type	Electronic
Fastest camera shutter speed	1/4 s
Flash modes	Auto, Flash off, Flash on
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MOV
Maximum video resolution	1024 x 1024 pixels
Internal memory	49.9 MB
Compatible memory cards	MicroSD (TransFlash)
Cables included	USB
Display diagonal	2.5 \
USB version	2.0
USB connector	Micro-USB

Weight and Dimensions

Depth	26.6 mm
Width	77 mm
Height	82.6 mm
Weight	138 g
