Copyright 2023 Cassia Networks, Inc.
Version: EN-2023039-YJ
gateway is installed, the user will identify this gateway on AC by the
gateway name easily, for example “Gateway 1 in factory A”.
AC Managed Gateway or Standalone Gateway
Bluetooth Tx power (limited by local regulatory requirements). The
default Tx power of E1000, S2000, and X2000 is 19dBm and is
configurable in 3/8/11/15/19 dBm. The default Tx power of X1000 is
20dBm and is configurable in 5/10/13/20 dBm. The Tx power of
Japan E1000, S2000, and X2000 is fixed in 8dBm. The Tx power of
Japan X1000 is fixed in 10dBm.
Tx gain of X2000’s internal Bluetooth antenna is 5.7dbi. If the gain
of the external Bluetooth antenna exceeds 5.7dbi, the Tx Power
should be decreased to the corresponding value in compliance with
local regulations.
Only valid for X2000. “None” means both Bluetooth chips use
internal Bluetooth antennas. “Chip 0” means chip 0 uses an external
antenna, but chip 1 still uses an internal antenna. “Chip 1” means
chip 1 uses an external antenna, but chip 0 still uses an internal
antenna. “Both” means both Bluetooth chips use external Bluetooth
antennas.
This parameter can only be changed on gateway’s local webpage, or
through Cassia AC RESTful API.
To check if the external antenna is enabled, the user can check if the
received RSSI changed.
Appendix I (Accessory Options) lists the candidate external antenna
and RF cables. These accessories have been verified by Cassia.
Statistics Report Interval
Cassia gateway reports statistical information to AC regularly. The
default statistic report interval is 30 seconds. This interval setting can
be increased to 1, 2, or 5 minutes.
If the user selects a cellular modem in the gateway’s console,
“Statistic Report Interval” will be changed to 5 minutes
automatically.
Enter the domain name or IP address of the Access Controller that
manages this gateway.
NOTE: AC server address is mandatory if AC is in the cloud or
MQTT is used for gateway and AC communication. If the AC server
address is empty, the gateway still can connect to the AC in the same
LAN with CAPWAP protocol.
AC-Gateway Protocol Priority
CAPWAP or MQTT. This is the high priority gateway-AC
communication protocol. If the gateway can’t connect to AC with this
protocol, it will try the low priority protocol automatically.
This configuration is available from firmware 2.0.2, and the factory
default setting is MQTT. If the gateway was upgraded from lower
versions, this value will be CAPWAP.
The communication UDP ports used by your AC and gateway. This
setting must be identical to the one set on your AC. Otherwise, your
gateway can’t talk to your AC.
When two or more network connections are activated, you can set
priority levels for the networks. By default, the priority is Wired >
Wi-Fi > Cellular. For example, if you set priority to Wi-Fi, the new
order will be: Wi-Fi > Wired > Cellular
Enable OAuth2 Token For
Local API
Enable OAuth2 token for Cassia local RESTful API. The default is
off.
By the way, if the user uses Cassia RESTful API through AC, please
do OAuth 2.0 authentication with the AC using the Developer Key
and Developer Secret (in AC setting page). It is not necessary to do
