Cattron MP96 Series User Manual

Cattron™ MP96/48 Series Portable Remote Control Systems
User Manual
30
68C-MP96/48-RD-EN
Version 006
4.14 MP96 Series – Specifications
Interface Type:
Solid state optically isolated relays – 12-250 VDC or 110-240 VAC, all fused
at 5 A
or
Mechanical relays with Normally Open (NO) contacts – 8 A at 250 VAC or 5 A
at 30 VDC; outputs fused at 5 A; Normally Closed (NC) contacts optional
or
Proportional volt free potentiometer
Output Termination:
Two screw terminals per relay contact allows mixed control voltages and
transformers (two control wires per terminal)
Number of Outputs:
Up to 96 independent and/or simultaneous, including Mainline ‘ON/OFF’
(OPRs)
Enclosure:
NEMA 12 (IP65) Standard – dust, oil and watertight
NEMA 4 and 4X (IP66) optional
Dimensions:
Standard Crane: 24" H x 24" W x 8" D (610 mm x 610 mm x 203 mm)
Electronic Sub-Chassis
(Gold Box):
Receiver, decoder and power supply each have their own EMI/RFI shielded
compartment; entire sub-chassis mounts on inside door of NEMA 12 (IP65)
enclosure with four nuts, allowing easy removal; no relays in sub-chassis
Control Voltage Range:
12-250 VAC or VDC at 0.55-5 A (higher voltages with derated current)
Proportional ‘Dry Potentiometer’ unipolar and bipolar
Power Requirements:
115 VAC 50-60 Hz or 12 VDC ±20%, at less than 1 A
Optional 12 to 250 VDC power regulators
Receiver Frequency:
UHF and VHF; maximum frequency span 5 MHz
Receiver Sensitivity:
0.5 µV (20 dB quieting) typical
Frequency Stability:
± 0.0005% of reference frequency
Environmental:
-22 F to +150 F (-30 C to +65 C), RH 0 to 95% Non-condensing
(Special units are available)
Microcomputer Speed
(Three):
11.059 MHz
Memory Size:
Two EPROMs, each with 1 MB of memory (programmed by Cattron)
Optional Diagnostic /
Programming Port:
Two RS232C (DB9 connector)
One RS485 (2-position terminal block)
