Display Line 1
Display Line 2
RF TEST MODE
HAS BEEN ACTIVATED
SUPERIO CHIP FAILED INIT
READ #1 (VALUE NOT 0x88)
SUPERIO CHIP FAILED INIT
READ #2 (VALUE NOT 0x00)
SUPERIO CHIP FAILED INIT
CLOCK ADDRESS INCORRECT
OPERATE TEST ACTIVE
WAITING TO GO ONLINE
RADIO DATALOG DOWNLOAD
HAS BEEN REQUESTED
RADIO DATALOG CLEAR
HAS BEEN REQUESTED
FATAL ERROR HAS OCCURRED
ON THE UCS MODULE
7.9.2 Standard Logged System Received Message Bulletin
These bulletins are relevant to digital data communications between the controller and receiver/decoder. As well
as being logged, some system received message bulletins may also be displayed during normal system operation
– refer to the section on Displayed System Bulletins. Some or all of the bulletins shown in Table 7 may be
displayed.
Table 7: Standard Logged System Received Message Bulletins
Display Line 1
Display Line 2
REQUEST TO SEND A
TALKBACK RX’D
XMITTED DATALOG CLEAR
HAS BEEN REQUESTED
XMITTED DATALOG DOWNLOAD
HAS BEEN REQUESTED
INVALID ADDRESS RECEIVED
ERROR EA
INVALID QSYNC BIT
ERROR Es
INVALID BCH RECEIVED
ERROR Eb
INVALID COMMAND WORD
ERROR EC
FRAMING ERROR RECEIVED
ERROR EF
INVALID SUBADDRES
ERROR Ed
BAD XMTR SWITCH GROUP 1
ERROR 91
BAD XMTR SWITCH GROUP 2
ERROR 92
BAD XMTR SWITCH GROUP 3
ERROR 93
BAD XMTR SWITCH GROUP 4
ERROR 94
BAD XMTR SWITCH GROUP 5
ERROR 95
