Cattron™ MP96/48 Series Portable Remote Control Systems
User Manual
35
68C-MP96/48-RD-EN
Version 006
Features
MP96
MP48
a standard parallel printer
Diagnostic datalog analysis and management software for IBM compatible
PC’s available
YES
NO
RS485 Serial port for interface to industry standard sensors
YES
NO
Parallel Printer Port
YES
NO
Remote download of datalog via RF link (PDDCTB)
YES
NO
Interface to Profibus, Modbus, and other Industry Standard Architecture
YES
NO
SPECIFICATIONS
Number of Outputs:
1-96 independent and/or simultaneous, including Mainline ON/OFF
YES
NO
Number of Outputs:
1-48 independent and/or simultaneous, including Mainline ON/OFF
YES
YES
Enclosure: NEMA 12 (IP65) standard – dust, oil and watertight; NEMA 4 and 4X
(IP66) optional
YES
YES
Sub-Chassis:
Receiver, decoder and power supply each have their own electromagnetic compliant
(EMC) shielded compartment; entire sub-chassis mounts on inside door of NEMA 12
(IP65) enclosure; no relays in sub-chassis
YES
YES
Dimensions:
Sub-chassis: Approximately 13" x 13" x 3" (330 mm x 330 mm x 100 mm)
NEMA 12 (IP65) enclosure, Standard Crane: 24" x 24" x 8" (610 mm x 610 mm x
203 mm)
YES
YES
Control Voltage Range:
30 VDC or 12-250 VAC fused at 5 A (higher voltages with de-rated current);
Stepless: 0-80 V Bi-polar Maximum
YES
YES
Power Requirements:
32/48/110/220 VAC 50-60 Hz or 13.7 VDC +/- 10% at less than 1 A
Optional 12 to 250 VDC power supplies available
YES
YES
Receiver Frequency:
(Crystal and Synthesized): UHF/VHF
YES
YES
