Cattron MP96 Series User Manual

Cattron™ MP96/48 Series Portable Remote Control Systems
User Manual
78
68C-MP96/48-RD-EN
Version 006
Table 5: Displayed System Bulletins
Display Line 1
Display Line 2
CPU TIMEOUT
PROCESSOR RESETTING
DECODER IS IN ESTOP
WAITING FOR VALID MESS
DECODER MOTOR WD OUTPUTS
ARE KILLED/DISABLED
*FAULT* SYSTEM SHUTDOWN
REPAIR & RESET CAUSE
TILT SWITCH ACTIVATED
DROPPED/TILTED XMITTER
WATCHDOG TIMEOUT FAILURE
[OPR1] - ERROR Fb
WATCHDOG TIMEOUT FAILURE
[OPR2] - ERROR Fs
WATCHDOG TIMEOUT FAILURE
[MAIN1]- [MAIN6] ERROR Fm
[OPR1] OUTPUT
ENABLE FAILED ONBOARD
[OPR2] OUTPUT
ENABLE FAILED ONBOARD
[MAIN1]-[MAIN6] OUTPUTS
ENABLE FAILED ONBOARD
[OPR1] OUTPUT FAILED
[ACTIVITY] ON - [OPR1]OFF
[OPR2] OUTPUT FAILED
[ACTIVITY] ON - [OPR2]OFF
LOOP FAULT [ACTIVITY] OFF
WHEN [OPR1] & [OPR2] ON
ASO FAULT [ACTIVITY] ON
WHEN [OPR1] & [OPR2] OFF
CODEPLUG VALUE INVALID
CHECK CODEPLUG
INTER-PROCESSOR
COMMUNICATIONS FAULT
RAM CHECK FAULT
CONTROL PROCESSOR
RAM CHECK FAULT
DATA PROCESSOR
*FAULT* -> ASO STAGE 2
HAS BEEN REACHED
PC DATALOG DOWNLOAD
HAS BEEN REQUESTED
PRINT DATALOG DOWNLOAD
HAS BEEN REQUESTED
ESTOP MESSAGE RECEIVED
ADDRESS [XX]*
NO POWER UP MESSAGE
ADDRESS [XX]*
NO NEUTRAL MESSAGE
ADDRESS [XX]*
ASO FAULT
[xxxxxxx] INPUT ON
ASO LOOP FAULT
[xxxxxxx] INPUT OFF
* where [XX] = address letter; e.g., 1A, 3C
Note: [xxxxxxx] is the label assigned to the module by the Cattron Application Engineering Department.
