15. Technical data
Optical
Operating range 1...10 m (3 ... 33 ft)
Number of elements 20, 22, 36, 42
Max. protection height 2,500 mm (98.5 in)
Max. ambient light 100,000 Lux
Mechanical
Cross section 12 mm × 14.5 mm
(0.47 in × 0.57 in)
Housing material Natural anodized
aluminum
Enclosure rating IP68 (Cable: IP67)
Temperature range −40 °C ... +60 °C
(−40 °F ... +140 °F)
Electrical
Supply voltage USP 10 ... 30 VDC
Current consumption with 50 mA
22 elements at 24 VDC
Output PNP/NPN (push-pull)
and FSS
Output load 100 mA, 100 nF
Typ. response time with 40 ms
22 elements
Max. response time with 80 ms
22 elements
HW Watch dog 200 ms
Max. door closing speed 1.6 m/s
Max. door opening speed > 3 m/s
Status LED Rx:
- Object detected red
- No object detected green
Power LED Tx:
Power ok green
Connection cable and electrical connection
Synchronization cable
Length 10 m (33 ft)
Connection Screwable M8, 4 pin
Diameter Ø 3.5 mm (Ø 0.14 in)
Material PVC, black
Plug color Black
Wires AWG26
• brown USP
• blue GND (0 V)
• black Communication
• white Not used
Connection cable
Length 5 m (16.5 ft)
Connection Screwable M8, 4 pin
Diameter Ø 4.2 mm (Ø 0.17 in)
Material PVC, black
Plug color Blue
Wires AWG26
• brown USP
• blue GND (0 V)
• black Output 1 (PNP/NPN and
FSS)
• white Test input
• gray Selectable output logic
• green Not used or Output 2
(PNP/NPN)
General
EMC emmision EN 61000-6-3:2007
EN 12015:2014
EMC immunity EN 61000-6-2:2005
EN 12016:2013
Vibration IEC 60068-2-6:2007
Shock IEC 60068-2-27:2008
RoHS 2011/65/EU
Certificates CE, TÜV
Safety categories EN ISO 13849-1:2015,
Cat. 2, PL D
EN 61508:2010, SIL 2
EN 12978:2009
EN 12453:2017 E device
Applicable standards UL 325:2012
