Assembly and operating instructions
CENTAX-G
020G-00050…00090-F.10
CENTA Antriebe Kirschey GmbH 28 / 52
Remove the pump for pushing on the hub from the shaft.
Turn the hub (3), drain oil out of the thread G¼ or G¾ (c) and dispose
correctly.
Screw the screw plug (19) into the hub (3).
Do not place a load on the hub for 24 hours.
Face of shaft must not protrude to face of hub. Otherwise radial replacement of other
coupling parts is not guaranteed.
