Centa CENTAX-G - Mounting the Rubber Element (1.1) and the Ring (20; if Existing) to the Adapter (4)

Assembly and operating instructions
CENTAX-G
020G-00050…00090-F.10
M020-00009-EN
Rev. 4
CENTA Antriebe Kirschey GmbH 35 / 52
6.10.3 Mounting the rubber element (1.1) and the ring (20; if existing) to the
adapter (4)
Fig. 6-10 Mounting the rubber element (1.1) and the ring (20; if existing)
to the adapter (4)
Item
Info
Designation
Remark
1.1
Rubber element
1.4
Ring
3
Hub
If scope of supply
4
Adapter
17
Adapter
If scope of supply
20
Ring
If scope of supply
34
Screw ISO4762-10.9
35
Washer ISO7089-300HV
C
Flywheel
Customer part
E
Flange
Customer part
