Centa CENTAX-G - After Completed Mounting

Assembly and operating instructions
CENTAX-G
020G-00050…00090-F.10
M020-00009-EN
Rev. 4
CENTA Antriebe Kirschey GmbH 41 / 52
Item
Info
Designation
Remark
1.1
Rubber element
1.2.1
Membrane
1.2.2
Ring
1.2.3
Bush
2x180°
1.2.4
Screw ISO4762-10.9
1.2.5
Nut ISO7040-10
1.2.6
Washer
1.2.7
Washer ISO7089-300HV
2x2x180°
1.2.8
Screw ISO4762-10.9
2x180°
1.2.9
Nut ISO7040-10
2x180°
e
Drilling for bush
In the rubber element (1.1)
h
Drilling for bush
In the membrane
X
Detail
IMPORTANT
Ensure during installation that the bushes are in the right position. The hole diameters
depending on coupling size are: ø10H7 or ø18H7.
 Turn the membrane (1.2.1) towards the rubber element (1.1) until the
drillings (e and h) for the bushes (1.2.3) are aligned.
 Push the bushes (1.2.3) into the drillings (e and h; 2x180°) of the rubber
element (1.1) and the membrane (1.2.1).
 Screw the rubber element (1.1), the bushes (1.2.3) and the membrane
(1.2.1) using the screws (1.2.8), the washers (1.2.7) and the nuts (1.2.9),
(2x180°).
 Screw the rubber element (1.1) and the membrane (1.2.1) using the
screws (1.2.4), the washers (1.2.6), the rings (1.2.2) and the nuts (1.2.5).
6.14 After completed mounting
WARNING
Injury and material damage can occur as a result of:
 Loose screw connections
Before commissioning, the tightening torque levels of all screws must
be checked and corrected if necessary.
Before commencing long-term operation, the plant must successfully complete a
test run.
