5.2. Cabling Requirements
NEW SITE INSTALLATION PREPARATIONSECTION 5
1
10
12
11
14
4
5
8
7
Legend
1. MAINS SUPPLY CABLE:
90V - 240V AC mains cable via double-pole mains
isolator-switch (3 core L.N.E. 1.5mm
2
SWA)
1,2
OR
15V AC TRANSFORMER SECONDARY (3 core L.N.E. 1.5mm
2
Cabtyre in Conduit)
2. Master Motor (Motor) (3 core 2.5mm
2
G.P. in Conduit or Norsk) AND
Master Motor (Limit Switch) (3 core 0.2mm
2
Intercom/Cabtyre/G.P. in Conduit)
3. Optional Slave Motor (Motor) (3 core 2.5mm
2
G.P. in Conduit or Norsk) AND
Slave Motor (Limit Switch) (3 core 0.2mm
2
Intercom/Cabtyre/G.P. in Conduit)
4. Optional intercom cable from motor to dwelling (n1 + 6 core
3
0.22mm
2
multi-strand
shielded cable)
5. Optional intercom cable from motor to entry panel (n2 0.22mm
2
multi-strand shielded
cable)
6. Optional but recommended infrared safety beams (3 core 0.22mm
2
multi-stranded)
4
7. Optional access control device (3 core 0.22mm
2
multi-stranded)
8. Optional pedestrian key-switch (2 core 0.22mm
2
multi-stranded) OR
9. Optional keypad (3 core 0.22mm
2
multi-stranded)
4
10. Optional external radio receiver (3 core 0.22mm
2
multi-stranded)
5
11. Optional pillar lights(3coreLNESWA,sizeaccordingtopowerrequirements)
6
12. Optional ground loop for free-exit
(1 core 0.5mm
2
multi-stranded – silicone coated)
7
13. Optional solenoid strike
8
(2 core 0.5mm
2
cable (ripcord) or G.P. in Conduit)
14. Optional solar panel (2 core 1.5mm
2
Cabtyre or G.P. in Conduit)
n1meansthenumberofcoresrequiredbyanintercom.
n2meansthenumberofcoresrequiredbyanintercom.
1. Possibly increase cable thickness if pillar lights are installed.
2. Type of cable must adhere to municipal bylaws but typically SWA (steel wire armoured) cable is recommended.
The armouring provides excellent screening, which gives better protection against lightning – earth one end of the screening).
3. Allows for all features such as pedestrian opening, status LED, etc., to be operated from the intercom handset inside the dwelling.
Number of cores and type of cable could vary depending on brand of access control system being used.
4. Wireless accessories are available. Please refer to www.censys.com for further information.
5. For optimum range, an external receiver can be mounted on the wall.
6. Requiresanexternalrelay.
7. Consultmanufacturerofloopdetectorforspecicdetails.
8. For distances greater than 5m, use cable with a thickness of at least 1mm².
For distances greater than 10m, use cable with a thickness of 1.5mm².
FIGURE 4. CABLING REQUIREMENTS
