CENTURION SYSTEMS R6 - Accessory Wiring Examples

page 30 www.centsys.com
FIGURE 32. EXAMPLE 1
CP77 Control
Card
12V/24V +
12V/24V -
COM
NO
NO
NC
COM
TX
NO CODING
SWITCHES
LEARN
ERASE
7.3. Radio Connections
ELECTRICAL CONNECTIONSSECTION 7
CENTURION RX
FIGURE 33. EXAMPLE 2
CP77 Control
Card
12V/24V -
12V/24V +
COM
NO
TYPICAL RADIO
RECEIVER
NO
NC
CODE
SWITCHES
COM
TYPICAL
TRANSMITTER
(REMOTE)
For details of setting code switches, refer
to radio manufacturer.
