INTRODUCTIONSECTION 1
1. Introduction
The R6 rotary swing gate system is designed to open and close swing gates. The CP77
controlleriscapableofhandlingbothsingleanddoubleswinggatesandoersmanyfeatures
to suit almost any application.
The unit employs a battery-driven DC motor for low-duty domestic applications, which
provides automatic backup protection in the event of a power failure. The unit can also be
ttedwithahigh-dutypowersupplyinadditiontothebatterytoallowformorefrequent
operation of the gate.
TheR6isttedwithaninternalelectroniclimitswitchsystem,whichprovidesreliableand
accurate positioning of the gate. This system allows the operator to smoothly slow the gate
down at the fully-open or -closed positions.
A fail-safe and highly reliable collision sensing system is built into the controller, which will
cause the motor to stop while the gate is opening, and stop and reverse when closing the
gate is obstructed in any way.
Gate movement is transmitted to the gate by means of articulated arms.
Icons used in this manual
This icon indicates tips and other information that could be useful during the
installation.
This icon denotes variations and other aspects that should be considered during
installation.
This icon indicates warning, caution or attention! Please take special
note of critical aspects that MUST be adhered to in order to prevent
injury.
