Connecting Cables to MHO-170
Quantum Maestro Getting Started Guide|115
Connecting to the Uplink Ports with Breakout Cables
Important - It is possible to connect breakout cables only to the top ports. When the
specific top ports are in a split mode, the corresponding bottom ports are disabled.
Example:
