MHO-175 Rear Panel
Quantum Maestro Getting Started Guide|25
MHO-175 Rear Panel
Item Description
1 First Power Supply Unit. See
"Replacing Power Supply Units" on page50
.
2 Fan Units 1, 2, 3, 4, 5, and 6 (from left to right). See
"Replacing Fan Units" on page52
.
3 Second Power Supply Unit. See
"Replacing Power Supply Units" on page50
.
