Connecting Cables to MHO-140
Quantum Maestro Getting Started Guide|121
Connecting Cables to MHO-140
In This Section:
Connecting to the Management Ports with DAC or Fiber Cables 121
Connecting to the Uplink Ports with DAC or Fiber Cables 123
Connecting to the Uplink Ports with Breakout Cables 125
Connecting to the Downlink Ports with DAC or Fiber Cables 128
Notes:
n
The different diagrams below show connections to different ports on the Quantum Maestro
Orchestrators.
n
It is possible to connect to the Quantum Maestro Orchestrator ports with a DAC cable, Fiber cable
(with transceivers), or Breakout cable.
n
The sections below provide a high-level description.
Connecting to the Management Ports with DAC or Fiber Cables
Important - When you connect two Quantum Maestro Orchestrators for redundancy, the
Check Point Management Server connects only to one of the Quantum Maestro
Orchestrators.
Example:
Note - The default Management ports are Ports 1-4. This diagram shows the connection to the Management
port 1. The same applies to the Management ports 2, 3 and 4.
