Connecting Two Quantum Maestro Orchestrators for Redundancy
Quantum Maestro Getting Started Guide|87
Connecting Two Quantum Maestro Orchestrators for
Redundancy
In This Section:
Diagram
87
Workflow
94
This section describes the connection of two Quantum Maestro Orchestrators for Redundancy on the same
site.
Diagram
Important:
n
It is possible to connect only two Quantum Maestro Orchestrators of the same
model (see MBS-5038).
n
You must connect cables to the same Uplink and Downlink ports on the two
Quantum Maestro Orchestrators (for example, if you connected to an Uplink port
4 on one Quantum Maestro Orchestrator, then you must connect to an Uplink port
4 on the other Quantum Maestro Orchestrator).
Notes:
n
This logical diagram is based on MHO-170, but applies equally to all Quantum Maestro Orchestrator
models.
n
This logical diagram shows two example Security Groups that contain two Security Appliances and
two Uplink ports each.
