Single Site
Quantum Maestro Getting Started Guide|82
Single Site
This section describes how to connect cables to Quantum Maestro Orchestrators on the same site.
Splitting the Ports with Breakout Cables
In This Section:
Breakout Cables
82
MHO-175 Splitting Options
83
MHO-170 Splitting Options
85
MHO-140 Splitting Options
86
Breakout Cables
With a breakout cable, it is possible to split one 100 / 40 GbE port into four 10 GbE ports.
Insert the splitter cables to convert each applicable QSFP28 100 GbE port into four SFP28 10 GbE ports.
Important - The breakout cable that splits 100 GbE port into four 25 GbE ports is not supported.
Example of a breakout cable:
