Connecting Cables to MHO-140
Quantum Maestro Getting Started Guide|125
Connecting to the Uplink Ports with Breakout Cables
Important - It is possible to connect breakout cables only to the top ports 49, 51, 53, and
55. When the specific top ports are in a split mode, the corresponding bottom ports are
disabled.
Example:
