Connecting Cables to MHO-140
Quantum Maestro Getting Started Guide|124
Explanations:
Item Description
1 Production network 1 that communicates with production network 2 (5) through a Security
Group configured on the Quantum Maestro Orchestrator.
2 Layer 2 switch.
3 A DAC or Fiber cable (with transceivers) connected to an Uplink port (in our example, Ports 7
and 49).
4 One of Quantum Maestro Orchestrators.
5 Production network 2 that communicates with production network 1 (1) through a Security
Group configured on the Quantum Maestro Orchestrator.
6 A DAC or Fiber cable (with transceivers) connected to an Uplink port (in our example, Ports 16
and 56).
7 Layer 2 switch.
Notes:
n
You assign the Uplink ports to the applicable Security Group.
n
It is possible to configure some of the Downlink ports as additional Uplink ports.
See the Maestro Administration Guide for your version > Chapter Configuration Procedure >
Section Configuring Security Groups > Section Configuring Security Groups in Gaia Clish > Section
Configuring the Port Settings .
