Dual Site with Direct Connection
Quantum Maestro Getting Started Guide|134
Item Description
9 DAC cables, Fiber cables (with transceivers), or Breakout cables that connect Downlink
ports on the
second
Quantum Maestro Orchestrator (11) on the
first
site to the Security
Appliance (17, 19 and 22) on the
first
site.
These cables connect to the
even
port of an Expansion Line Card on Security Appliances.
10 The dedicated external synchronization port (Port 47) on the
second
Quantum Maestro
Orchestrator (3) on the
first
site.
This port connects with a DAC cable or Fiber cable (with transceivers) to the dedicated
external synchronization port (13) on the
second
Quantum Maestro Orchestrator (14) on
the
second
site.
11 The
second
Quantum Maestro Orchestrator on the
first
site.
12 DAC cables, Fiber cables (with transceivers), or Breakout cables that connect Downlink
ports on the
second
Quantum Maestro Orchestrator (14) on the
second
site to the Security
Appliance (18, 21 and 24).
These cables connect to the
even
port of an Expansion Line Card on Security Appliances.
13 The dedicated external synchronization port (Port 47) on the
second
Quantum Maestro
Orchestrator (14) on the
second
site.
This port connects with a DAC cable or Fiber cable (with transceivers) to the dedicated
external synchronization port (10) on the
second
Quantum Maestro Orchestrator (11) on
the
first
site.
14 The
second
Quantum Maestro Orchestrator on the
second
site.
15 The dedicated internal synchronization port (Port 48) on the
second
Quantum Maestro
Orchestrator (3) on the
first
site.
This port connects with a DAC cable to the dedicated internal synchronization port (7) on
the
first
Quantum Maestro Orchestrator (3) on the
first
site.
Important:
n
This connection is only used to synchronize the configuration of Security
Groups between the Quantum Maestro Orchestrators.
n
MHO-175 and MHO-170 require a 100 GbE DAC or 40 GbE DAC cable.
n
MHO-140 requires a 10 GbE DAC cable.
16 The dedicated internal synchronization port (Port 48) on the
second
Quantum Maestro
Orchestrator (14) on the
second
site.
This port connects with a DAC cable to the dedicated internal synchronization port (7) on
the
first
Quantum Maestro Orchestrator (6) on the
first
site.
Important:
n
This connection is only used to synchronize the configuration of Security
Groups between the Quantum Maestro Orchestrators.
n
MHO-175 and MHO-170 require a 100 GbE DAC or 40 GbE DAC cable.
n
MHO-140 requires a 10 GbE DAC cable.
17 Security Appliance 1 on the
first
site - member of the Security Group (20).
Table: Explanations (continued)
