Dual Site with Direct Connection
Quantum Maestro Getting Started Guide|137
Step Instructions
3 On each site, connect fiber cables (with transceivers)or DAC cables between the
dedicated external synchronization ports on the Quantum Maestro Orchestrator.
Procedure
n
You must connect fiber cables between ports with the same numbers on the
Quantum Maestro Orchestrators on each site.
Connect fiber cables between these pairs of Quantum Maestro Orchestrators:
1. The first Orchestrator on the first site (Orchestrator ID 1_1).
The first Orchestrator on the second site (Orchestrator ID 2_1).
Connect ports with the same numbers.
2. The second Orchestrator on the first site (Orchestrator ID 1_2).
The second Orchestrator on the second site (Orchestrator ID 2_2).
Connect ports with the same numbers.
Best Practice:
l
On MHO-175 and MHO-170, use Ports 31 on the Quantum
Maestro Orchestrators on each site.
l
On MHO-140, use Ports 47 on the Quantum Maestro
Orchestrators on each site.
l
Do not use ports with the configured type "management".
n
It is possible to use any port for external synchronization, except these ports:
l
The ports already used for the internal synchronization.
l
The disabled ports, if you used breakout cables. See
"Splitting the Ports
with Breakout Cables" on page82
.
