Dual Site with two Switches
Quantum Maestro Getting Started Guide|149
Item Description
23 The dedicated internal synchronization port (Port 48) on the second Quantum Maestro
Orchestrator (19) on the first site.
This port connects with a DAC cable to the dedicated internal synchronization port (15) on
the first Quantum Maestro Orchestrator (11) on the first site.
Important:
n
This connection is only used to synchronize the configuration of Security
Groups between the Quantum Maestro Orchestrators.
n
MHO-175 and MHO-170 require a 100 GbE DAC or 40 GbE DAC cable.
n
MHO-140 requires a 10 GbE DAC cable.
24 The dedicated internal synchronization port (Port 48) on the second Quantum Maestro
Orchestrator (22) on the second site.
This port connects with a DAC cable to the dedicated internal synchronization port (16) on
the first Quantum Maestro Orchestrator (14) on the first site.
Important:
n
This connection is only used to synchronize the configuration of Security
Groups between the Quantum Maestro Orchestrators.
n
MHO-175 and MHO-170 require a 100 GbE DAC or 40 GbE DAC cable.
n
MHO-140 requires a 10 GbE DAC cable.
25 Security Appliance 1 on the first site - member of the Security Group (28).
26 Security Appliance 1 on the second site - member of the Security Group (28).
27 Security Appliance 2 on the first site - member of the Security Group (28).
28 Security Group that contains Security Appliances from both sites (25, 26, 27, 29, 30 and
31).
29 Security Appliance 2 on the second site - member of the Security Group (28).
30 Security Appliance 3 on the first site - member of the Security Group (28).
31 Security Appliance 3 on the second site - member of the Security Group (28).
Table: Explanations (continued)
