LEDs
Quantum Maestro Getting Started Guide|37
Power Supply Unit LED on the Rear Panel
The primary PSU is located on the left side, and the secondary PSU is located on the right side of the
Quantum Maestro Orchestrator.
The PSU Status LEDs are located on the PSUs themselves.
Each PSU has one LED of its own.
Power Supply Unit LED - Rear Panel in MHO-175
Power Supply Unit LED - Rear Panel in MHO-170
Power Supply Unit LED - Rear Panel in MHO-140
