LEDs
Quantum Maestro Getting Started Guide|40
After you connect a breakout cable to a port, you get four additional interfaces starting from the original
interface name. You assign these interfaces to Security Groups.
Example - When you connect a breakout cable to the top port 8 (interface "eth1-29"), you get:
Port
Number
on the
Front
Panel
Interface
Name
in Gaia OS
Port
Name
in Gaia OS
8 eth1-29 Port 1/8/1
eth1-30 Port 1/8/2
eth1-31 Port 1/8/3
eth1-32 Port 1/8/4
Note - For more information about the ports and interface names in Gaia, see "Quantum Maestro
Orchestrator Ports and Gaia OS Interfaces" on page170 .
