LEDs
Quantum Maestro Getting Started Guide|43
Port LEDs on MHO-170
In MHO-170, the status of each pair of adjacent ports is indicated by two LEDs:
Example:
Port LED Behavior:
LED Behavior Port State Action Required
Off Link is down. Check the cable.
Steady green Link is up, but there is no traffic. None.
Flashing green Link is up, and the traffic is flowing. None.
Flashing amber A problem with the link. Check the cable, and replace if needed.
