Connecting Two Quantum Maestro Orchestrators for Redundancy
Quantum Maestro Getting Started Guide|89
Explanations:
Item Description
1 Network 1 connected to ports on the Networking Device (3).
2 Network 2 connected to ports on the Networking Device (3).
3 Networking Device (router or switch) that connects your Network 1 and Network 2 to the
Quantum Maestro Orchestrators (15 and 16) with Bond interfaces (Link Aggregation).
4 Bond interface that connects Network 1 to the Quantum Maestro Orchestrators (15 and 16).
This Bond interface provides a redundant Uplink connection for the traffic inspected by the
Security Appliances (29 and 30) in the applicable Security Group (31).
5 Bond interface that connects Network 2 to the Quantum Maestro Orchestrators (15 and 16).
This Bond interface provides a redundant Uplink connection for the traffic inspected by the
Security Appliances (26 and 27) in the applicable Security Group (28).
6 SmartConsole Client that connects to the Management Server (7).
7 Management Server that manages Security Groups configured on the Quantum Maestro
Orchestrators (15 and 16).
8 Layer 2 switch.
9 A Breakout cable connected to the Management port 1. See "Splitting the Ports with Breakout
Cables" on page82 .
Note - You assign this Management port (or these split interfaces) to the applicable
Security Groups. Shared Management feature allows to assign the same
Management port (interface ethX-MgmtY) on a Quantum Maestro Orchestrator to
different Security Groups. The assigned Management port has a different IP
address and a different MAC address in each Security Group, to which this port is
assigned.
10 A DAC cable, Fiber cable (with transceivers), or Breakout cable that connects a first slave of
the first Bond (4) on the Networking Device (3) to the first Quantum Maestro Orchestrator (15).
11 A DAC cable, Fiber cable (with transceivers), or Breakout cable that connects a second slave
of the first Bond (4) on the Networking Device (3) to the second Quantum Maestro
Orchestrator (16).
12 A DAC cable, Fiber cable (with transceivers), or Breakout cable that connects a first slave of
the second Bond (5) on the Networking Device (3) to the first Quantum Maestro Orchestrator
(15).
13 A DAC cable, Fiber cable (with transceivers), or Breakout cable that connects a second slave
of the second Bond (5) on the Networking Device (3) to the second Quantum Maestro
Orchestrator (16).
Table: Explanations
