MENU TREE
ORP AUTO
Calibrate mV 750
Setpoint mV 700
Alarm Low mV 650
Alarm High mV 850
Time Limit min 30
Run Time 10 125
Last Shock 05/01/98
SANITIZER OFF
Calibrate ppm 1.5
Setpoint ppm 1.5
Alarm Low ppm 0.3
Alarm High ppm 3.0
Time Limit min 30
Run Time 10 125
Last Shock 00/00/00
CONTROL TYPE
OFF
Manual
Automatic
Timer
CALIBRATION
1 Point (Zero)
2 Point (Slope)
3 Point (Curve)
ALARM OPTIONS
Feed Lockout YES
Buzzer YES
SHOCK & SAVER
Shock Treatment
Chemical Saver
ON/OFF
Proportional
4-20 mA
Cycle ON 0.1
Cycle OFF 1.0
Deadband
Deadband
Progressive Zone
Top Limit
Bottom Limit
pH AUTO
Calibrate 7.5
Setpoint 7.5
Alarm Low 7.0
Alarm High 8.0
Time Limit min 30
Run Time 10 25
Probe Clean AUTO
CLEAN ON OFF
Mo 19:00 19:05
Tu 00:00 00:00
We 19:00 19:05
Th 00:00 00:00
Fr 00:00 00:00
Sa 19:00 19:05
Su 00:00 00:00
TDS AUTO
Calibrate ppm 1650
Setpoint ppm 2000
Alarm Low ppm 50
Alarm High ppm 2500
Time Limit min 30
Run Time 10 25
Select Scale
Cell Constant 1
TDS Factor 0.5
HEATER AUTO
Calibrate F 82
Setpoint F 82
Alarm Low F 70
Alarm High F 85
Time Limit min 30
Run Time 15 60
Energy Saver AUTO
Heating
Cooling
Acid Feed
Base Feed
Both
Oxidizer
Reducer
Both
ENERGY SAVER
Mo 19:00 06:00
Tu 19:00 06:00
We 19:00 06:00
Th 19:00 06:00
Fr 19:00 06:00
Sa 19:00 06:00
Su 19:00 06:00
PUMP AUTO
P influent psi 25
P effluent psi 20
Flow Rate gp m 800
Alarm low gpm 500
Flow Total Mga 2.20
Heater Delaymin 20
Water Level AUTO
PUMP ON OFF
Mo 05:00 20:00
Tu 05:00 20:00
We 05:00 20:00
Th 05:00 20:00
Fr 05:00 20:00
Sa 05:00 20:00
Su 05:00 20:00
PRESSURE ALARMS
Low psi + 10
High psi + 50
FLOWMETER FACTOR
Pulses/ga: 6.705
FILTER AUTO
Backwash Date 8/10
Start Time 15:30
Filter Time (min)10.0
Advance (min) 1.0
Number of Filters 5
Pump shutdownYES
Pump Override YES
CONFIGURATION
Initial Setup
Operations
Reports
Communications
Time Interval
P Differential
Time or Pressure
Time & Pressure
Flow rate
Volume of water
Volume or Pressure
Volume & Pressure
Number of Filters5
Priority Valve YES
PUMP Override YES
Stop Time between
valves (sec) 10
COMMUNICATIONS
Phone
Unit ID
Alarm calling YES
INITIAL SETUP
Language
Units
Password
Clock Set
Readings
Data Logging
Model Options
MODEL OPTIONS
ORP Yes
SANITIZER Yes
p H Yes
CONDUCTIVITY Yes
HEATER Yes
PUMP Yes
FILTER Yes
PHONE NUMBERS
1: ______________
2: ______________
3: ______________
4: ______________
5: ______________
6: ______________
SATURATION
Alkalinity 150
Hardness 300
pH 7.5
Temperature 80
Langelier Limits
Langelier Index
Condition OK
OPERATIONS
Audio Alarms YES
Bypass Line YES
Saturation OK
Print Reports
Reset
Battery
Probe Monitor YES
Complete Reset
Partial Reset
ORP
SANITIZER
pH
CONDUCTIVITY
HEATER
PUMP
FILTER
LANGUAGE
English
French
Spanish
UNITS
U.S.
Metric
MENU TREE CHEMTROL
(R)
PC CONTROLLERS
Decrease
Increase
SHOCK AUTO
Date 05/08/98
Cycle (days) 7
Time ON pH 18:00
Level pH 7.8
Time ON shock 21:00
Level ORP 820
Time OFF 21:30
View data log
Print Reports
