Chino KP3000 User Manual

- 40 -
⑭ Program pattern information
FNC code……Application function code, R/W……R: READ, W: WRITE
Reference
number
FNC
Code
R/W Data name
Setting range
(Communication
range)
Initial value Remarks
49003
03
06
16
R
W
W
[Program pattern
for R/W]
Pattern No.
1 to 30
(1 to 30)
1
(Pattern 1)
Setting for Reading/Writing of
program pattern (reference
49005 to 49045)
1 = PTN01 (pattern 1)
to
30 = PTN30 (pattern 30)
*Set before reading/writing of
pattern information.
*Written pattern number is
stored until tuning off the
power of instrument.
*Reading/writing of pattern
number of this reference is
dedicated data for
reading/writing program
pattern information by
communications. When
read/write pattern number
during program operation,
use reference 49066/30126.
49004
03
06
16
R
W
W
[Program pattern
for R/W]
Step No.
0 to 19
(0 to 19)
0
(Step 0)
Setting for Reading/Writing of
program pattern (reference
49005 to 49045)
1 = STP00 (pattern 0)
to
19 = STP19 (pattern 19)
*Set before reading/writing of
pattern information.
*Written step number is
stored until tuning off the
power of instrument.
*Reading/writing of step
number of this reference is
dedicated data for
reading/writing program
pattern information by
communications. When
read
/
write step number during
program operation, use
reference 49066/30126.
49005
03
06
16
R
W
W
[Program pattern]
Step repeat
0 to 99, FFh
(0 to 99, FFh)
FFh
(Blank
display)
0 = Repeat starting step
1 to 99 = Repeat ending step
FFh = Blank display
(Excepting start/end step)
*Read/write after writing
reference 49003 and 49004.
*Writing is not possible when
reference 49004 is step 0 or
after the final step.
49006
03
06
16
R
W
W
[Program pattern]
SV
Within the range
of SV limit
(Within the range
of SV limit)
0.0
･Decimal point position = SV
decimal point
*Read/write after writing
reference 49003 and 49004.
*Writing is not possible when
reference 49004 is after the
final step.
