Page #44 background imageLoading...
Page #44 background image
- 41 -
FNC code……Application function code, R/W……R: READ, W: WRITE
Reference
number
FNC
Code
R/W Data name
Setting range
(Communication
range)
Initial value Remarks
49007
03
06
16
R
W
W
[Program pattern]
Time
‘Hours’ or
‘Minutes'
000 to 999
(0 to 999)
0
(Hours or
minutes)
Setting of HHH of HHH:LL
Unit = Every time unit
*Read/write after writing
reference 49003 and 49004.
*Writing is not possible when
reference 49004 is step 0 or
after the next step of the final
step (= final step + 1).
*When write to the next step
of the final step, step is added
to end of the pattern.
49008
03
06
16
R
W
W
[Program pattern]
Time
‘Minutes’ or
‘Seconds'
00 to 59
(0 to 59)
0
(Minutes or
seconds)
Setting of LL of HHH:LL
Unit = Every time unit
*Read/write after writing
reference 49003 and 49004.
*Writing is not possible when
reference 49004 is step 0 or
after the next step of the final
step (= final step + 1).
*When write to the next step
of the final step, step is added
to end of the pattern.
49010
03
06
16
R
W
W
[Program pattern]
SV No.
.0 to 8
(0 to 8)
[STEP1]
1 (No.1)
[From STEP2]
0 (No.0)
0 = No.0 (continue of the prior
step number)
1 to 8 = No.1 to 8
*Read/write after writing
reference 49003 and 49004.
*Writing is not possible when
reference 49004 is step 0 or
after the final step.
49020
49021
49022
49023
49024
49025
49026
49027
03
06
16
R
W
W
[Program pattern]
Time signal No.
“TS1”
“TS2”
“TS3”
“TS4”
“TS5”
“TS6”
“TS7”
“TS8”
0 to 20
(0 to 20)
0
(OFF)
0 = OFF (All OFF)
1 to 8 = No.1 to No.8
11 to 18 = No.1R to No.8R
(repeat)
20 = ON (ALL ON)
*Read/write after writing
reference 49003 and 49004.
*Writing is not possible when
reference 49004 is step 0 or
after the final step.
49040 03 R
[Program pattern]
Existing step
count
End step No.
0 to 19
(0 to 19)
0
(No setting
step)
(Step 0)
0 = No setting step
to
19 = Setting step number 19
0 = STP00 (Step 0)
to
19 = STP19 (Step 19)
*No writing
*Read/write after writing
reference 49003.
*Step No. setting of reference
49004 is not necessary.
