FNC code……Application function code, R/W……R: READ, W: WRITE
Reference
number
FNC
Code
R/W Data name
Setting range
(Communication
range)
Initial value Remarks
49041
03
06
16
R
W
W
[Program pattern]
Start SV
Range of
measurement
range
Range of liner
scale
0
・Decimal point position = SV
decimal point
*Read/write after writing
reference 49003.
*Setting of step No. of
reference 49004 is not
necessary.
49043
03
06
16
R
W
W
[Program pattern]
Link destination
pattern No.
0 to 19
(0 to 19)
0
(Non link)
0 = Non pattern link
1 = Link to pattern 1
19 = Link to pattern 19
*Read/write after writing
reference 49003.
*Setting of step No. of
reference 49004 is not
necessary.
49048
03
06
16
R
W
W
Time unit
0/1
(0/1)
0
(H:M)
0= H:M (Hours:Minutes)
1= M:S(Minutes:Seconds)
* When program operation is
other than during RESET,
writing is not possible.
49049
03
06
16
R
W
W
SV during reset
Within the range
of SV limit
(Within the range
of SV limit)
0
*When no transmission signal
output and communication
function is other than TRANS,
writing is not possible.
49055
03
06
16
R
W
W
Pattern repeat
0 to 9999
(0 to 9999)
0 times
