Chino KP3000 User Manual

- 47 -
FNC code……Application function code, R/W……R: READ, W: WRITE
Reference
number
FNC
Code
R/W Data name
Setting range
(Communication
range)
Initial value Remarks
49093
03
06
16
R
W
W
[Pattern/step
editing]
Pattern copy
[READ]
0/1/2/3/4/5
(0/1/2/3/4/5)
[WRITE]
0102h to 1E1Dh
(0102h to 1E1Dh)
-
Reading of [pattern/step] status
[READ] (FNC_03)
0= No edition
1= Add step
2= Delete step
3= Pattern copy
4= Pattern clear (1 pattern)
5= Clear all patterns
Pattern copy
[WRITE] (FNC_06, FNC_16)
1= PTN1 (pattern 1)
to
30= PTN30 (pattern 30)
･High order 8 bits = Copy source
pattern No.
･Low order 8 bits = Copy source
pattern No.
High order 8 bit Low order 8 bit
*When copy source pattern is not set
(step number in existence (reference
49040) is 0 step), writing (pattern
copy) is not possible.
*When copy destination pattern is not
erased (step number in existence
(reference 49040) is other than 0
step). Writing (pattern copy) is not
possible.
→ After clear in copy destination
pattern (reference 49094), perform
pattern copy.
*When copy destination pattern No.
and copy source pattern No. is same,
writing (pattern copy) is not possible.
*Continuous writing is not performed
from reference 49093 to 49096 by
FNC16 (function cord).
49094
03
06
16
R
W
W
[Pattern/step
editing]
Pattern clear
[READ]
0/1/2/3/4/5
(0/1/2/3/4/5)
[WRITE]
0 to 30
(0 to 30)
-
Reading of [pattern/step] status
[READ] (FNC_03)
0= No edition
1= Add step
2= Delete step
3= Copy pattern
4= Clear pattern (1 pattern)
5= Clear all patterns
Pattern clear
[WRITE] (FNC_06, FNC_16)
0= Clear all pattern (All pattern
information is initialized.
1= PTN1 (Pattern 1 is initialized)
to
30= PTN30 (Pattern 30 is initialized)
*Caution: When write [0], all
pattern information is initialized.
*When program operation (reference
49067) is other than RESET, writing
is not possible.
Copy source
pattern No.
Copy destination
pattern No.
15 8 7 0
