F4.26
F4.27
F4.22
F4.23
F4.24
F4.25
-
-
0 ~ 1000
(0.00 ~ 600.00) Hz
(0.0 ~ 300.0)%
(0.00 ~ 600.00) Hz
reserve
reserve
Oscillation suppression active
power filter coefficient
Oscillation suppression start
frequency
Oscillation suppression active end
load
Oscillation suppression end
frequency
-
-
950
2.00Hz
300%
60.00Hz
F5 group input terminal parameter group
F5.00
F5.01
F5.02
F5.03
F5.04
F5.05
F5.06
reserve
1
1
2
9
12
0
0
reserve
X1 terminal function selection
X2 terminal function selection
X3 terminal function selection
X4 terminal function selection
X5 terminal function selection
X6 terminal function selection
0 ~ 63
0: no function
1: Forward running FWD
2: Run REV in reverse
3: forward jogging
4: reverse jogging
5: Three-wire operation control
6: Fault reset
7: External fault input
8: reserved
9: Running pause
10: External terminal shutdown
11: reserved
12: Free parking
13: Terminal UP
14: Terminal DOWN
15: Command switch to keyboard control
16: command switch to terminal control
17: Command to switch to communication control
18: The main frequency source is switched to digital
reference
19: The main frequency source is switched to AI1
20: The main frequency source is switched to AI2
21: reserved
22: reserved
23: reserved
24: Multi-segment command terminal 1
25: Multi-segment command terminal 2
26: Multi-segment command terminal 3
27: Multi-segment command terminal 4
28: Acceleration and deceleration time selection
terminal 1
29: Acceleration and deceleration time selection
terminal 2
30~33: reserved
34: Forward rotation prohibited
35:Reverse prohibition
36: Acceleration and deceleration prohibited
37: UP/DN setting reset
38: reserved
39: reserved
40: reserved
41: reserved
42: reserved
43: PID integral pause
44: PID prohibited
45: The direction of PID action is reversed
46: reserved
47: reserved
48: DC braking
49: Frequency setting effective terminal
50: reserved
51: The current running time is cleared
52~63: reserved
function
code
name
Parameter Description
Defaults
Change
092
NVF2G-S Series Inverter User's Guide
