CHINT NVF2G-S Series - Page 102

F5.45
F5.46
F5.47
F5.56
F5.57
F5.58
F5.59
F5.48
F5.49
F5.50
F5.51
F5.52
F5.53
F5.54
F5.55
-
-
-
-
-
-
-
( 0.000 ~ + 30.000)V
( 0.000 ~ + 30.000)V
( 0.000 ~ + 30.000)V
( 0.000 ~ + 30.000)V
( 0.000 ~ + 30.000)V
( 0.000 ~ + 30.000)V
( 0.000 ~ + 30.000)V
( 0.000 ~ + 30.000)V
reserve
reserve
reserve
reserve
reserve
reserve
reserve
AI1 measured voltage 1
AI1 display voltage 1
AI1 measured voltage 2
AI1 display voltage 2
AI2 measured voltage 1
AI2 display voltage 1
AI2 measured voltage 2
AI2 display voltage 2
-
-
-
-
-
-
-
2.000V
2.000V
8.000V
8.000V
2.000V
2.000V
8.000V
8.000V
F6 group output terminal parameter group
F6.00
F6.04
F6.01
F6.02
F6.03
–
Setting range: 0x0000~0x0007 Binary setting:
0 : Enabled and valid
1 : Disconnect is valid
Units:
BIT0～BIT2 : Y1 , RO1 , RO2
Tens: Reserved
–
0x0000
1
16
1
reserve
Valid state setting of output
terminal ( Y1, RO1 , RO2)
Y1 output selection
Relay RO 1 output selection
Relay RO2 output selection
0 ~ 63
0: no output
1: The inverter is running
2: Frequency level detection FDT1 arrival
3: Frequency level detection FDT2 arrival
4: Inverter overload pre-alarm
5: Undervoltage status output
6: External fault shutdown
7: The upper limit frequency is reached
8: The lower limit frequency is reached
9: Running at zero speed
10~14: reserved
15: The drive is ready to run
16: Fault output
17~18: reserved
19: Torque limited
20: Speed direction
21: reserved
22: Frequency arrival
23: reserved
24:Unloading
25: Zero current state
26: Current reaches 1
27 : The current reaches 2
28: Module temperature reaches
29: The output current exceeds the limit
30: reserved
31: Motor overload pre-alarm
32: reserved
33: reserved
34: Arrive on time
35:AI1>AI2
36: reserved
37: The current running time is reached
38~63: reserved
function
code
name
Parameter Description
Defaults
Change
094
NVF2G-S Series Inverter User's Guide
