CHINT NVF2G-S Series User Manual

Table 9.4 Detailed Description of Control Parameters
Function
Description
address
definition
Data Meaning Description
Power-down
save
Read and
write
properties
Communication
control command
( communication
control when
F0.01 = 2 )
0x3200
0x00 : no command
no
W
0x01 : Forward running
0x02 : reverse operation
0x03 : stop running
0x04 : Forward jogging
0x05 : reverse jogging
0x06 : jogging stop
0x07 : free stop
0x08 : fault reset
Inverter status
0x3300
bit00 : run / stop ( 0 stop, 1 run)
/
R
bit01 : reverse / forward rotation ( 0 forward
rotation, 1 reverse rotation)
bit02 : Zero speed running ( 1 is valid)
bit03 : Accelerating ( 1 is valid)
bit04 : Deceleration in progress ( 1 is valid)
bit05 : Constant speed operation ( 1 is valid)
bit06 : In pre-excitation ( 1 is valid)
bit07 : Tuning in progress ( 1 is valid)
bit0 8: overcurrent limit ( 1 is valid)
bit09 : DC overvoltage limiting ( 1 valid)
bit10 : In torque limit ( 1 is valid)
bit11 : In speed limit ( 1 is valid)
bit12 : Inverter fault ( 1 is valid)
bit13 : speed control ( 1 is valid)
bit14 : Reserved
bit15 : undervoltage ( 0 undervoltage)
Inverter running
state display
parameter address
0x3400
Output frequency
/
R
0x3401
set frequency
0x3402
bus voltage
0x3403
The output voltage
0x3404
Output current
0x3405
Operating speed
0x3406
Output Power
0x3407
output torque
0x3408
PID given
0x3409
PID feedback
0x340A
Input terminal status
0x340B
Output terminal state
0x340C
reserve
0x340D
Analog AI1 value
0x340E
Analog AI2 value
0x340F
reserve
0x3410
reserve
0x3411
PLC current segment speed
0x3501
bus voltage
0x3502
Input terminal status
Inverter stop state
display parameter
address
0x3500
set frequency
/
R
069
NVF2G-S Series Inverter User's Guide
