CHINT NVF2G-S Series - Page 98

function
code
name
Parameter Description
Defaults
Change
F1 group start-stop control group
F1.00
F1.01
F1.02
F1.04
F1.05
F1.06
F1.07
F1.08
F1.09
F1.10
F1.11
F1.12
F1.13
F1.14
F1.03
0: start from the starting frequency
1: Brake first and then start from the starting
frequency
2: Speed tracking (including direction discrimination)
restart
(0.00 ~ 10.00)Hz
(0.0 ~ 100.0)s
(0.0 ~ 100.0)s
0: decelerate to stop
1: free stop
2: Deceleration to stop + DC braking
0.00Hz ～F0.07
( 0.0 ~ 10 0. 0 ) s
(0.0 ~ 100.0)% (inverter rated current)
(0.00 ~ 100.0 ) s
(0.0 ~ 300.0)s
0: switch at the lower limit of running frequency
F0.09
1: Switch at starting frequency F1.01
–
–
–
(0.0 ～ 100.0)% (inverter rated current)
0
0.00Hz
0.0s
0.0s
0
0.00Hz
0.0s
0.0%
0.0s
0.0s
0
–
–
–
0.0%
Starting mode
Starting frequency
Starting frequency hold time
DC braking time before starting
Shutdown mode
Start frequency of DC braking at
stop
Stop DC braking waiting time
Stop DC brake current
Stop DC braking time
Forward and reverse dead time
Forward and reverse switching
mode
reserve
reserve
reserve
DC braking current before starting
F2 group first motor parameter group
F2.00
F2.01
F2.02
F2.03
F2.04
F2.05
F2.06
F2.08
F2.09
F2.10
F2.07
0: Ordinary asynchronous motor
(0.1 ~ 1000.0)kW
1V ~ Inverter rated voltage
(0.01～ 600.00 ) A (inverter power<=55kW)
(0.1～6 000.0 ) A (inverter power>55kW)
0.01Hz ~ maximum output frequency F0.07
2 to 24
(0 ~ 65535)rpm
(0.001～65.535) Ω (inverter power<=55kW)
(0.0001～6.5535) Ω (inverter power>55kW)
(0.01～655.35)mH (inverter power<=55kW)
(0.001～65.535)mH (inverter power>55kW)
(0.1～6553.5)mH (inverter power<=55kW)
(0.01～655.35)mH (inverter power>55kW)
(0.001～65.535) Ω (inverter power<=55kW)
(0.0001～6.5535) Ω (inverter power>55kW)
0
Model
confirmed
Model
confirmed
Model
confirmed
Model
confirmed
Model
onfirmed
1430
Tuning
parameters
Tuning
parameters
Tuning
parameters
Tuning
parameters
motor type
Motor rated power
Motor rated voltage
Motor rated current
Motor rated frequency
Number of motor poles
Motor rated speed
Asynchronous motor rotor
resistance
Asynchronous motor leakage
inductance
Mutual inductance reactance of
asynchronous motor
Asynchronous motor stator
resistance
090
NVF2G-S Series Inverter User's Guide
