Local Operation
4-7
Figure 4-2 CV Response Transfer Function (FAST)
Figure 4-3 CV Response Transfer Function (SLOW)
4. Set Current spec
Set the high current spec. to 8 A by pressing 8, ENTER.
Set the low current spec. to 4 A by pressing 4, ENTER.
Then the display will go to the first editing page again.
5. In constant voltage mode, the voltage setting should be greater than Von Point. It is
suggested to set the Von Point to 0.
Ex: In CVL mode, set the voltage measurement range to low in CONF.
Press CONF and select 2:
HIGH : 8.000A
LOW : 4.000A
To Next Page
