Appendix E Specification Verification
66200 Series 0.1A Range
Fluke 5500 Output Parameter Max. Spec. Measured Result Min. Spec.
High Current
100V/ 0.1Arms
60Hz
Irms 0.1004 0.0996
Low Current
100V/ 0.01Arms
60Hz
Irms 0.0103 0.0097
High Current
100V/ 0.01Arms
10K Hz
Irms 0.010031 0.009969
66200 Series 0.01A Range
Fluke 5500 Output Parameter Max. Spec. Measured Result Min. Spec.
High Current
100V/ 0.01Arms
60Hz
Irms 0.01004 0.00996
Low Current
100V/ 0.001Arms
60Hz
Irms 0.00103 0.00097
High Current
100V/ 0.001Arms
10K Hz
Irms 0.001031 0.000969
20A Range (66202 Only)
Fluke 5500 Output Parameter Max. Spec. Measured Result Min. Spec.
100V/ 10Arms
60Hz
Irms 2.06 1.94
100V/ 2Arms
60Hz
Irms 2.052 1.948
100V/ 2Arms
400Hz
Irms 2.052 1.948
8A Range (66202 Only)
Fluke 5500 Output Parameter Max. Spec. Measured Result Min. Spec.
100V/ 8Arms
60Hz
Irms 8.0176 7.9824
100V/ 0.8Arms
60Hz
Irms 0.8104 0.7896
100V/ 0.8Arms
400Hz
Irms 0.8104 0.7896
E-5
