Digital Power Meter 66200 Series User’s Manual
2A Range (66202 Only)
Fluke 5500 Output Parameter Max. Spec. Measured Result Min. Spec.
100V/ 2Arms
60Hz
Irms 2.0044 1.9956
100V/ 0.2Arms
60Hz
Irms 0.2026 0.1974
100V/ 0.2Arms
400Hz
Irms 0.2026 0.1974
0.2A Range (66202 Only)
Fluke 5500 Output Parameter Max. Spec. Measured Result Min. Spec.
100V/ 0.2Arms
60Hz
Irms 0.20044 0.19956
100V/ 0.02Arms
60Hz
Irms 0.002044 0.019956
100V/ 0.02Arms
400Hz
Irms 0.002044 0.019956
Voltage Frequency Measurement Specification Verification
Steps:
1. Set the voltage range of 66200 Series Power Meter to 150Vrms and current range to 2A,
special measurement display is set to F (frequency).
2. Follow the test table to set the voltage, frequency output of Fluke 5500A.
3. Press OPR to set the Fluke 5500A to begin output.
4. Log the voltage frequency showed on the 66200 Series Power Meter special measurement
display panel.
5. Follow the test table to set the voltage, frequency output of Fluke 5500A.
6. Repeat step 3 and 4 to log the 66200 Series Power Meter panel readings.
7. Once the test is completed, set the Fluke 5500A output to Standby.
The test result of frequency measurement for 66200 Series Power Meter:
Fluke 5500 Output Max. Spec. Measured Result Min. Spec.
150V/ 60Hz 60.012 59.988
150 V/ 10KHz 10002 9998
40V/50Hz 50.01 49.99
40V/15Hz 14.996 15.005
Power Measurement Specification Verification
The test tables of verification are divided into 66202 and 66201 Power Meters that cannot be
mixed for use. The digital filter must set to OFF when using 66202 Power Meter during
measuring at 400Hz.
E-6
