DESCRIPTION FIGURE
FRONT RAIL
Front Rail
FRONT RAIL PHEV Front Rail PHEV
BODY SIDE APERTURE Body Side Aperture
INNER BODY SIDE COMPONENTS DO NOT SECTION AREAS Inner Body Side Components-Do Not Sec-
tion
INNER QUARTER PANEL Inner Quarter Panel
LIFTGATE TROUGH AND D-PILLAR REINFORCEMENTS Liftgate Trough And D Pillar Reinforcements
ROOF D-PILLAR COMPOSITE REINFORCEMENTS Roof D-pillar Composite Reinforcements
THIRD ROW SEAT TUB Third Row Seat Tub
REAR RAIL Rear Rail
Front Frame Rail
NOTE: Right side shown, left side similar.
1 - Outer Front Frame Rail (590 MPa)
2 - Sectioning Cut Line
3 - Measure From Center Of The Front Cradle Bolt Hole
WARNING: Sectioning of components may only be performed in the described areas if damage to
component does not extend past sectioning location. Should damage extend past sectioning
location entire component replacement is the only acceptable repair
WARNING: Failure to follow these directions may result in serious or fatal injury
