Chrysler PACIFICA 2017 - Inner Body Side Components; Very High Strength Steel (VHS) Reinforcements and Panels

Inner Body Side Components - Do Not Section
NOTE: Left side shown, right side similar
VERY HIGH STRENGTH STEEL (VHS) REINFORCEMENTS AND PANELS — DO NOT
SECTION
1- A-pillar Inner Panel (1300 MPa)
2- Bodyside Front Door Ring Reinforcement (1300 MPa)
3- T-bone Roof Side Rail Inner Panel (1300 MPa)
4- Sliding Door Track Upper Reinforcement (780 MPa)
5- C-pillar Outer Upper Reinforcement (690 MPa)
6- Sill Outer Rear Reinforcement (780 MPa)
7- Sill Outer Front Reinforcement (1300 MPa)
Due to the usage of VHS on the inner components and reinforcements sectioning of these parts are not allowed.
Complete replacement of the component or reinforcement is the only acceptable repair.
It will be necessary to use a Tungsten Carbide Drill Bit to release the spot welds along the areas where these
parts join other components.
Do Not Section
