MATERIAL TYPE COLOR
Seam Sealer Blue
DESCRIPTION FIGURE
Hood
Figure 1
Front Door Figure 2
Sliding Door Figure 3
Liftgate Figure 4
Front Wheelhouse Panel Figure 5
Engine Box Figure 6
Engine Box (Lower View) Figure 7
Front Wheelhouse Outer Figure 8
Cowl Side Panel and Load Path Beam Figure 9
Cowl Side Panel Figure 10
Plenum/Dash Panel Figure 11
Cowl Plenum/Dash Panel Figure 12
Dash Panel (Interior) Figure 13
Sill Inner Reinforcement Figure 14
Dash Panel and Front Floor (Interior) (1 of 2) Figure 15
Dash Panel and Front Floor (Interior) (2 of 2) Figure 16
Front Floor Underbody Figure 17
Inner A-pillar Panel Figure 18
Front Door Ring Reinforcement (1 of 2) Figure 19
Front Door Ring Reinforcement (2 of 2) Figure 20
Body Side Aperture Front Figure 21
Sill Inner Reinforcement Figure 22
Rear Sill Inner Panel Figure 23
Rear Sill Figure 24
Front Door Ring (Inner Lower) Figure 25
Door Lower Track and Lower B-pillar Figure 26
Roof Panel With Sunroof (1 of 3) Figure 27
Roof Panel With Sunroof (2 of 3) Figure 28
Roof Panel With Sunroof (3 of 3) Figure 29
Roof Panel Standard (1 of 2) Figure 30
Roof Panel Standard (2 of 2) Figure 31
Center and Mid Floor (Interior) Rear View Figure 32
Center and Mid Floor (Interior) Front View Figure 33
Center Floor and Front Floor Pan Underbody Figure 34
Center and Mid Floor (Interior) Figure 35
Upper Sliding Door Track Upper Reinforcement Figure 36
Body Side Aperture (Top) Figure 37
Mid Floor Pan Figure 38
Floor Pan and Third Row Seat Tub Underbody (1 of 2) Figure 39
