CIGWELD 170Oi - ASSEMBLY PROCEDURE; Installing Base Panel

TRANSTIG 170Pi
Manual 0-5242 8-1 ASSEMBLY PROCEDURE
SECTION 8:
ASSEMBLY PROCEDURE
8.01 Installing Base Panel
1. Base Panel
2. Secure HF PCB to Base Panel with four plastic umbrella-shape screws.
3. Secure Inverter PCB with the four screws.
4. Inverter PCB
1
2
Art # A-11832
2
3
4
Figure 8-1: Installing Base Panel
