TRANSTIG 170Pi
KEY SPARE PARTS 9-2 Manual 0-5242
TRANSTIG 170Pi POWER SOURCE SPARE PARTS
ITEM PART NUMBER DESCRIPTION
1 W7005815 PCB Power
2 W7005801 PCB Control
3 W7005802 PCB HF Generator
4 W7005803 PCB Front Panel (Display)
5 W7005805 Knob Control
6 W7004909 Dinse Socket 50mm
2
7 W7005811
Control Socket 8 pin (Note that 8 pin control plug is part number
UOA706900)
8 W7005812
Shielding Gas Outlet 5/8-18
9 W7005804 HF Coupling Coil Assembly
10 W7005814 CT Output
11 W7004908 Shielding Gas Solenoid Valve Assembly
12 W7005605 Shielding Gas Inlet Quick Connect
13 W7005813 Input Supply On/Off Switch
14 W7004913 Shielding Gas Hose Assembly
15 W7005806 Fan Assembly
16 W7003010 Input Rectifier (Shown mounted to PCB Power, item 1)
17 704461 Dinse Plug Male 50mm
2
(not shown)
Table 9-1
To Next Page
