Cimarron ARCONTROL BMS - System Operation; AUTOMATIC Mode

62
Table 3.5.1 · MODBUS register map - conguraon registers (connued)
REGISTER
NUMBER
NAME DESCRIPTION
OPTIONS and
REGISTER VALUE
DEFAULT
DATA
TYPE
READ
or
WRITE
81
SHUTDOWN
2 LOGIC
Operang logic of Shutdown 2
Logic Value
0 UINT16 R/W
HIGH ON
LOW OFF
0
HIGH OFF
LOW ON
1
WINDOW 2
INV
WINDOW
3
82
SHUTDOWN
2 HIGH
LEVEL
Shutdown 2 upper limit
Range Value
1 INT16 R/WMin -32768
Max 32768
83
SHUTDOWN
2 LOW LEVEL
Shutdown 2 lower limit
Range Value
0 INT16 R/WMin -32768
Max 32768
84 - 89 UNUSED Unused N/A R
90
SHUTDOWN
3 SOURCE
Input used for Shutdown 3
Source Value
0 UINT16 R/W
Ø (NONE) 0
TC1 1
TC2 2
TC BMS 3
XDCR 4
PS1 5
PS2 6
91
SHUTDOWN
3 LOGIC
Operang logic of Shutdown 3
Logic Value
0 UINT16 R/W
HIGH ON
LOW OFF
0
HIGH OFF
LOW ON
1
WINDOW 2
INV
WINDOW
3
92
SHUTDOWN
3 HIGH
LEVEL
Shutdown 3 upper limit
Range Value
1 INT16 R/WMin -32768
Max 32768
93
SHUTDOWN
3 LOW LEVEL
Shutdown 3 lower limit
Range Value
0 UINT16 R/WMin -32768
Max 32768
